Our Complete Range of Pick & Carry Mini Cranes

Manual Cranes

Specs Valla 18EValla 22EValla 25E
Max Lifting Capacity 1,800 kg2,250 kg2,500 kg
Max Working Height 4.8 m4.8 m4.8 m
Max Working Radius 3.0 m2.7 m2.7 m
Total Machine Weight 2,180 kg1,970 kg2,400 kg

Radio Controlled

Specs Valla V36RValla V46RValla V60RValla V70RValla V80RValla V100RXValla V110RValla V130RXValla V160RValla V180RValla V210RValla 250E
Max Lifting Capacity 3,600 kg4,600 kg6,000 kg7,000 kg8,000 kg10,000 kg11,000 kg13,000 kg16,000 kg18,000 kg21,000 kg25,000 kg
Max Working Height 7.5 m7.2 m7.8 m9.2 m9.2 m9.1 m10.1 m10.1 m12.5 m12.5 m12.5 m13.2 m
Max Working Radius 4.7 m4.7 m4.9 m5.5 m5.4 m5.5 m6.2 m6.2 m8.1 m8.1 m8.1 m9.2 m
Capacity @ Max Height 1,800 kg2,450 kg4,100 kg4,200 kg4,600 kg5,100 kg7,500 kg8,200 kg10,400 kg10,800 kg11,200 kg3,600 kg
Capacity @ Max Radius 450 kg620 kg900 kg1,000 kg1,800 kg2,260 kg2,500 kg3,100 kg3,200 kg4,200 kg5,100 kg1,900 kg
Power Source Batteries Batteries Batteries Batteries Batteries Batteries Batteries Batteries Batteries Batteries Batteries Batteries
Height 1,560 mm1,560 mm2750 mm1886 mm1886 mm1895 mm1979 mm1981 mm2000 mm1980 mm2000 mm2319 mm
Length 2,465 mm2,465 mm1180 mm3262 mm3262 mm3262 mm3709 mm3709 mm4490 mm4490 mm4490 mm4832 mm
Width 900 mm900 mm1747 mm1400 mm1400 mm1460 mm1500 mm1525 mm1980 mm2000 mm1980 mm2150 mm
Total Machine Weight 3,900 kg4,300 kg5,800 kg7,500 kg8,350 kg8,400 kg11,400 kg11,400 kg19,750 kg20,750 kg20,750 kg24,200 kg

Cabin Cranes

Specs Valla V160RCValla V180RCValla V210RCValla 250E
Max Lifting Capacity 16,000 kg18,000 kg21,000 kg25,000 kg
Max Working Height 12.5 m12.5 m12.5 m13.2 m
Max Working Radius 8.1 m8.1 m8.1 m9.2 m
Capacity @ Max Height 10,400 kg10,800 kg11,200 kg3,600 kg
Capacity @ Max Radius 3,200 kg4,200 kg5,100 kg1,900 kg
Power Source Batteries Batteries Batteries Batteries
Height 1945 mm1980 mm2000 mm2319 mm
Length 4490 mm4490 mm4490 mm4832 mm
Width 2000 mm2000 mm1980 mm2150 mm
Total Machine Weight 19,980 kg20,980 kg23,500 kg24,200 kg

Carry Deck

Specs Valla 100SEValla 160SEValla 180SEValla 220SE
Max Lifting Capacity 10,000 kg16,000 kg18,000 kg22,000 kg
Max Working Height 9.5 m11.6 m16.1 m15.5 m
Max Working Radius 7.5 m10.5 m13.5 m13.5 m
Capacity @ Max Height 1,500 kg7,000 kg6,500 kg8,100 kg
Capacity @ Max Radius 500 kg4,000 kg1,300 kg1,650 kg
Power Source Batteries Batteries Batteries Batteries
Height 2555 mm2845 mm2995 mm2948 mm
Length 4980 mm6375 mm7265 mm7265 mm
Width 1900 mm2695 mm2450 mm2450 mm
Total Machine Weight 11,450 kg16,200 kg23,600 kg24,000 kg
